The Keysight 1141A is a 1X FET differential probe with 200 MHz bandwidth and 3000:1 CMRR (Common Mode Rejection Ratio) at 1 MHz. The probe has an input resistance of 1 MΩ and low input capacitance of 7 pF, to minimize circuit loading.
The Keysight 1141A 200 MHz Differential Probe must be used with the Keysight 1142A Probe Control and Power Module. It can be connected to any instrument with 50 ohm inputs. An external 50 ohm termination can also be used with high impedance inputs.HP Agilent Keysight 1141A 200 MHz 1:1 Differential Probe
You are here: Probe » Oscilloscope
Above pictures can be different from actually sold item as well as the installed options. On request we'll send you high resolution pictures and options of the real item.
Product description
Features
- Superior tolerance to ESD
- Low dc thermal drift
- ±200 V (dc + peak ac) maximum allowable input without attenuators
- Dc offset and dc reject
- Remote control input coupling and offset
- Rugged construction
- Requires the 1142A probe control and power module
- Compatible with 5000, 6000, 7000 and 9000 Series oscilloscopes
- Max. Frequency: 200 MHz
Price
€ 490,00
