HP Agilent Keysight, 85640A
Above pictures can be different from actually sold item as well as the installed options. On request we'll send you high resolution pictures and options of the real item.
Product description

The Keysight 85640A is a portable tracking generator to be used with the Keysight 8560A, 8561A/B, or 8562A/B portable spectrum analyzer.

Combining the Keysight 85640A tracking generator with a portable spectrum analyzer results in a system having both scalar-analysis and spectrum-analysis capabilities. Use the scalar-analysis capability to perform measurements such as gain, frequency reponse, compression, flatness, and return loss on components and subsystems. Use the spectrum analysis capability to measure harmonic and inter-modulation distortion, as well as spurious products.

Features
  • Frequency Range: 300 kHz - 2.9 GHz
  • Output level range: -80 dBm - 0 dBm
  • Flatness: 2 dB
  • Min RBW supported 300 Hz; 100 Hz (8561A, 8562A/B)
  • Compatibility: 8560A, 8561A/B, or 8562A/B
  • Max. Frequency: 2.9 GHz
  • Min. Frequency: 300 KHz
  • Max. Level: 0 dBm
  • Min. Level: -80 dBm
Price
 € 1.000,00
