HP Agilent Keysight, E4443A
Above pictures can be different from actually sold item as well as the installed options. On request we'll send you high resolution pictures and options of the real item.
Product description
The E4443A PSA high-performance spectrum analyzer measures and monitors complex RF signals up to 6.7 GHz.
Features
  • Frequency Range: 3 Hz - 6.7 GHz
  • RBW: 1Hz - 8MHz
  • EMI bandwidths (CISPR compliant): 200 Hz, 9 kHz, 120 kHz, 1 MHz
  • EMI bandwidths (MIL STD 461E compliant): 10 Hz, 100 Hz, 1 kHz, 10 kHz, 100 kHz, 1 MHz
  • +/-0.19 dB absolute amplitude accuracy
  • -155 dBm (-168 dBm w/preamp) displayed average noise level (DANL)
  • -118 dBc/Hz phase noise at 10 kHz offset
  • Compatibility: EMI
  • Max. Frequency: 6.7 GHz
  • Min. Frequency: 3 Hz
  • Max. Level: +30 dBm (1 W)
  • Min. Level: -155 dBm (-168 dBm w/preampl)
  • Min. Resolution: 1 Hz
  • Tracking generator: optional
