Marconi, 6960B
Above pictures can be different from actually sold item as well as the installed options. On request we'll send you high resolution pictures and options of the real item.
Product description
The Marconi 6960B RF Power Meter is a high accuracy instrument which together with its associated power sensors provides measurements at frequencies from 30 kHz up to 46 GHz over a wide range of power levels. Its numeric keyboard enables easy manual control while full GPIB implementation with SRQ mask and trigger modes make it the logical choice for fast ATE systems.

Features:
• Extensive frequency coverage: 30 kHz to 46 GHz
• Wide dynamic range: -70 dBm (100 pW) to +44 dBm (25W)
• Fast response on GPIB of 25 ms
• Auto averaging with manual override
• Both 50 Ω and 75 Ω sensors
• Low sensor VSWR reduces measurement uncertainty
• Sensor linearity correction for improved accuracy
• Maximum hold facility
• Optional DC operation
• Non-volatile memory
  • Max. Frequency: 46 GHz
  • Min. Frequency: 30 kHz
  • Channels: 1
  • Max. power: 44 dBm
  • Min. Power: -70 dBm
Price
 € 380,00
