Product Specs:
- Frequency Range: 32 to 900 MHz
- Setting: Keyboard
- Resolution:
- 100 kHz Steps: 32.0 to 99.9 MHz
- 250 kHz Steps: > 100 MHz
- Tolerance:
- < 25 kHz: 32 to 300 MHz
- < 35 kHz: 300 to 470 MHz
- < 50 kHz: 470 to 900 MHz
- RF Output Voltage: > 10 mV
- Impedance: 75 Ohm
- Attenuation: > 60 dB continuous
- Frequency Response:
- ±2 dB: 32 to 300 MHz
- ±3 dB: 300 to 470 MHz
- ±2 dB: 470 to 900 MHz
- Video Input Voltage: 1 Vpp
- Video Output Voltage: 0 to 1.5 V
