Tektronix, TDS684B
Above pictures can be different from actually sold item as well as the installed options. On request we'll send you high resolution pictures and options of the real item.
Product description
The Digital Real-Time architecture of the TDS 684B simplifies capturing intermittent signals or non-recurring problems like glitches or metastable states caused by setup and hold time violations. The TDS684B provides design engineers excellent single shot accuracy for multi-channel, high speed signal characterization.
Features
  • Bandwidth: 1 GHz
  • Channels: 4
  • Sample Rate: 5Gs/s
  • 8-Bit Vertical Resolution
  • Greater than 11-Bits with Averaging
  • Record Length: 15,000 Points
  • 1 mV/div to 10 V/div Sensitivity
  • 1.5% Vertical Accuracy
  • Waveform Math and Advanced Waveform DSP
  • 1 ns Peak Detect
  • Channel Deskew
  • Fully Automated Measurement System
  • Waveform Pass/Fail Template Testing
  • Color VGA Display
  • 3.5 in. DOS Format Floppy Drive
  • RS-232, Centronics, GPIB and VGA I/O Ports
  • Time base: double
  • Channels: 4
  • Display: CRT color
  • BandWidth: 1000 MHz
  • Sampling: 5 Gs/s
